Run YOLOv8 on the Core 3588E NPU

This guide builds the YOLOv8 example from Rockchip's rknn_model_zoo on Core 3588E and runs object detection on a sample image with the NPU. Everything is done on the module itself.

Before you start

• Core 3588E is running Mixtile OS (see Flashing an OS Image) and is connected to the internet.
• You are logged in on the desktop, over SSH or on the serial console.

Mixtile OS already includes the RKNN runtime (librknnrt) that runs models on the NPU, so you do not need to install it.

Step 1. Install the build tools

Core 3588E

sudo apt update
sudo apt install -y build-essential cmake git

Step 2. Download the example and the model

1. Clone rknn_model_zoo into your home directory:

   Core 3588E

   cd ~
   git clone https://github.com/airockchip/rknn_model_zoo

2. Download the yolov8n.rknn model into the example's model directory:

   Core 3588E

   cd ~/rknn_model_zoo/examples/yolov8/model
   wget https://downloads.mixtile.com/doc-files/yolov8/rk3588/yolov8n.rknn

   This model is yolov8n.onnx converted for the RK3588 NPU. To convert a model yourself, see Convert to RKNN.

Step 3. Build the example

Core 3588E

cd ~/rknn_model_zoo
CFLAGS="-Wno-error=incompatible-pointer-types -Wno-error=implicit-function-declaration" \
bash build-linux.sh -t rk3588 -a aarch64 -d yolov8

The CFLAGS are needed because the GCC version in Mixtile OS treats two old patterns in the example's code as errors. They turn those errors back into warnings.

Expected result: the build ends by installing the example to ~/rknn_model_zoo/install/rk3588_linux_aarch64/rknn_yolov8_demo/:

rknn_yolov8_demo
├── lib
├── model
│   ├── bus.jpg
│   ├── coco_80_labels_list.txt
│   └── yolov8n.rknn
├── rknn_yolov8_demo
└── rknn_yolov8_demo_zero_copy

Step 4. Run object detection

The example takes a model and an input image:

Core 3588E

cd ~/rknn_model_zoo/install/rk3588_linux_aarch64/rknn_yolov8_demo
./rknn_yolov8_demo model/yolov8n.rknn model/bus.jpg

The input image is model/bus.jpg, a street photo of a city bus with people walking in front of it.

Expected result: the output lists each detected object with its label, box coordinates and confidence score:

person @ (211 241 282 506) 0.864
bus @ (96 136 549 449) 0.864
person @ (109 235 225 535) 0.860
person @ (477 226 560 522) 0.848
person @ (79 327 116 513) 0.306

The same detections are drawn on the image and saved as out.png in the current directory:

Troubleshooting

Problem	What to do
The build stops with error: implicit declaration of function 'cos' or error: initialization of 'char *' from incompatible pointer type	Run the build command in step 3 with the CFLAGS shown there.
You are not sure which RKNN runtime the example uses	Run ldd rknn_yolov8_demo | grep rknnrt in the example directory. On Mixtile OS it shows /usr/lib/aarch64-linux-gnu/librknnrt.so.
